Wall Mount Residential Energy Storage Battery 30KWh

Short Description:

1.Mainly used for storing electrical energy in home energy systems. We can also provide you with a complete set of home energy system construction solutions.

2.This product adopts a vertical floor-standing design, with a simple and beautiful appearance and does not take up space in the home.

3.Through communication with the inverter, we can use the APP to monitor and manage our battery work.

4.This product has a single capacity of up to 28.6KWh of electricity, which meets most power usage scenarios and matches most inverter models on the market, with excellent compatibility.


Product Detail

Detailed Diagram

Product Tags

Product Feature

1. One machine can handle all household electricity:

51.2V/560AH large capacity

2. Up to 15 modules can be connected, reaching 426 KWh

3. AAA-level battery cells, excellent performance

4. >6000 cycle life, 5-year product warranty, product life of more than 10 years

5. The product can be used in extreme weather, with optional heating function

6. LiFePo4 battery is environmentally friendly, safe and durable

7. The BMS system we developed has excellent performance, which can achieve high-speed charging and efficient discharge

Parameter



51.2V560Ah

Nominal Voltage

51.2V

Nominal Capacity

560Ah

Charge Voltage

46.4-58.4V

Charge Current

200A

Max Charge Current

200A

Charging Mode

Constant Current / Constant Voltage

Discharge Cut-off Voltage 51.2V
Discharge Current

200A

Max Discharge Current

200A

Charge Temperature

-10~50℃

Discharge Temperature

-20℃ to 60℃, -4°F to 140°F

Storage Temperature

0℃ to 40℃, 32°F to 104°F

Cycle Life

≥6000 Cycles @0.3C/0.3C

Commnication Port

RS485/CAN

Battery size(L)*(W)*(H) 1100*525*525mm
Weight                                             247kg
Shell Material

Sheet metal chassis

Protection Class

IP55

Installation Method

Wall mounted

Certificate

UN38.3/MSDS/CE

Accepatable

OEM/ODM,Trade,Wholesale,Regional Agency

MOQ

1/piece

Scenario
